Technical Parameter
| Lengthregion | 5m-6m |
| Seatsregion | 15seats- |
| Model | Bus |
| Year | 1972-01-01 |
| Engine | Gasoline 3TZ |
| transmission | 5MT |
| Fuel_type | Gasline |
| Dimensions | 5460×1880×2285 |
| Lengthregion | 5m-6m |
| Seatsregion | 15seats- |
| Model | Bus |
| Year | 1972-01-01 |
| Engine | Gasoline 3TZ |
| transmission | 5MT |
| Fuel_type | Gasline |
| Dimensions | 5460×1880×2285 |
| Vehicle model | 5.4m gasoline-2.7L |
|
| QTY | 10 units | 4 units |
| Engine model | 3TZ | |
| Driver's seat | LHD | |
| Fuel type | Gasoline | |
| Displacement (L) | 2.693 | |
| Emission standard | Euro V | |
| Rated.output(kw/rpm) | 120/4600～5000 | |
| Max.torque(N.m/rpm) | 260/2600～3600 | |
| length×width×height(mm) | 5460×1880×2285 | |
| Wheelbase(mm) | 3110 | |
| Rear axle speed ratio | 4.556 | |
| Seat arrangement | 15 fabric seats | |
| Fuel tank capacity(L) | 70 | |
| Curb weight(kg) | 2220 | |
| Max.speed(km/h) | 120 | |
| Wheeltread(mm) | 1665/1650 | |
| Tire | 195/R15LT Radial tyre |
|
| Transmission type | 5MT | |
| Brake system | Front disc, rear drum, ABS+EBD, initiative vacuum booster |
|
| Suspension system | Front double wishbone independent suspension/rear variable rate leaf spring |
|
| Steering assembly | H78 gear rack type hydraulic power steering gear |
|
