Technical Parameter
| Lengthregion | 8m-9m |
| Seatsregion | 21-30seats |
| Model | Bus |
| Year | 2021-10-06 |
| Engine | WEICHAI Engine |
| Fuel_type | Natural Gas |
| Dimensions | 8995×2500×3400 |
| Seats | 21-30 |
| Lengthregion | 8m-9m |
| Seatsregion | 21-30seats |
| Model | Bus |
| Year | 2021-10-06 |
| Engine | WEICHAI Engine |
| Fuel_type | Natural Gas |
| Dimensions | 8995×2500×3400 |
| Seats | 21-30 |
| TEG6890NG01 Technical States | ||
| Overall dimensions (mm) | 8995×2500×3400 | |
| Front suspension/ wheelbase/rear suspension | 1940/4280/2775 | |
| Rated passenger capacity | 61/16-30 | |
| Curb weight (kg) | 9800 | |
| Total mass (kg) | 3500 | |
| Approach angle/ departure angle (°) | 10/8 | |
| Axle load of front axle/rear axle (kg) | 4500/9000 | |
| Project | Technical Configuration Parameters | Remark |
| Engine | In-line, direct injection, water-cooling, four-stroke, charge inter-cooling, high-pressure common rail, three-way catalysis, WP7NG210E61 | WEICHAI |
| Gearbox | Mechanical, QJ805, three flexible shafts | Qijiang |
| Suspension | 3 for front and 4 for rear | |
| Front axle | Bearing capacity 4.5T, maintenance-free grease lubricated hub assembly | |
| Rear axle | Bearing capacity 9T, maintenance-free grease lubricated hub assembly | |
| Wheel rim | 7.5×22.5 steel | Zhengxing |
